Installation Instructions

M
Master Valve
The master valve wire is labeled
“M”. If you have a master valve,
wire it into the “M” terminal.
S1, S2, 24VAC
Sensor Wires (Optional)
You are able to connect up to
two rain or flow sensors to your
controller using the “S1,” “S2,” and
24VAC sensor power terminals.
For more information, visit:
www.environet.us/sensors
2. Create an account to
get started.
1. Download the Environet app from
the Apple App Store, or Google
Play, or by scaning the QR code.
Step 6
Install Environet APP
C 1 2 3 4 5 6 7 8 9 10 11
12 13 14 15 16
M C S1 S2
24VAC
- +
16 Zones
