Installation Instructions

Photograph
Wiring
Remove the old
controller
Mount to a wall
Step 2
Take a photo of the old wiring
Take a picture of the internal wiring of the
old controller. This will come in handy for
later wiring.
Step 3
Remove the old controller
Unplug and remove the old controller.
Step 4
Install smart controller
Screw the mounting board to the wall.
Align the holes on the back of the
controller with the protrusions for
installation. Ensure that the wiring and
power adapter can reach the controller.
