Installation guide

C2RPS-POE Redundant Power Supply Output Connector
A-2 Specifications
C2RPS-POE Redundant Power Supply Output Connector
Forpinlocationandfunction,refertoFigure A‐1andTable A‐2,respectively.
Figure A-1 C2RPS-POE Redundant Power Supply Connector Pin Locations
Physical
Dimensions 4.45 H x 44.5 W x 16.5 D (cm)
1.75 H x 17.5 W x 6.5 D (in.)
Net Weight (unit only)
Gross Weight (1 unit and packaging)
3.47 kg (7.63 lb)
4.95 kg (10.89 lb)
MTBF 589,644 Hours at 25°C (77°F)
Environmental
Operating Temperature 5°C to 40°C (41°F to 104°F)
Storage Temperature -30°C to 73°C (-22°F to 164°F)
Operating Relative Humidity 10% to 90%
Table A-1 C2RPS-POE Specifications (continued)
Item Specification
Note: The following information is for troubleshooting purposes only. For proper operation,
do not use any other cable except the C2RPS-POE Cable. This cable is specially
designed for this application and meets all necessary Regulatory and Safety standards.
The use of non-approved cables will void your warranty.
