About This Guide This guide provides an overview, installation and troubleshooting instructions, and specifications for the Enterasys® SecureStack B2G124‐24, B2G124‐48, and B2H124‐48 stackable Ethernet switches. For information about the Command Line Interface (CLI) set of commands used to configure and manage the switches, refer to the Enterasys Networks® SecureStack B2 Configuration Guide.
How to Use This Guide How to Use This Guide Read through this guide completely to familiarize yourself with its contents and gain an understanding of the features and capabilities of the stackable Ethernet switches. A general knowledge of data communications networks is helpful when setting up the switches. This preface provides an overview of this guide and the SecureStack B2 manual set, a brief summary of each chapter and defines the conventions used throughout this guide.
Conventions Used in This Guide Conventions Used in This Guide The following conventions are used in this guide: Note: Calls the reader’s attention to any item of information that may be of special importance. Caution: Contains information essential to avoid damage to the equipment. Precaución: Contiene información esencial para prevenir dañar el equipo. Achtung: Verweißt auf wichtige Informationen zum Schutz gegen Beschädigungen.
Conventions Used in This Guide xviii About This Guide
1 Introduction This chapter introduces the B2G124‐24, B2G124‐48, and B2H124‐48 stackable switches. Important Notice Depending on the firmware version used in the switch, some features described in this document may not be supported. Refer to the Release Notes shipped with the B2G124-24, B2G124-48, and B2H124-48 to determine which features are supported. For information about... Refer to page...
Overview Overview The B2G124‐24, B2G124‐48, and B2H124‐48 are stackable Fast Ethernet and Gigabit Ethernet switches, which can be adapted and scaled to help meet your network needs. These switches provide a management platform and uplink to a network backbone for a stacked group of up to eight B2 switches. The four built‐in Small Form Pluggable (SFP) interface slots provide you with the option of installing Mini‐GBICs for 1000BASE‐SX/LX fiber‐optic connections and 1000BASE‐T copper connections.
Overview Figure 1-1 B2G124-24 Stackable Switch à ŠFront 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 1 11 13 23 2 12 14 24 21 22 21 22 23 24 B2G124-24 MGR Console RPS UP CPU À Back 23 24 DOWN Á Ä Â Redundant Power Supply STACK UP AC LINE 100-240 VAC 50-60 Hz 0.
Overview B2H124-48 The B2H124‐48 (Figure 1‐3) has the following front and rear panel port connections: • RJ45 ports (10/100 Mbps 100BASE‐TX copper ports). • SFP slots that provide you with the option of installing Small Form Pluggable (SFP) Mini‐GBICs for 1000BASE‐SX/LX fiber‐optic connections and 1000BASE‐T copper connections. • Rear panel connectors for high‐speed connections in a stack configuration.
Connectivity High-Speed Stack Connections The switches have rear‐panel connectors for high‐speed connections in a stack configuration. The high‐speed stacking cables used for the connections are optional items and must be ordered separately. Stacking cables are available in three lengths: 1 foot, 1 meter and 5 meters. See “Connecting High‐Speed Stacking Cables” on page 3‐10 for details on these cables.
Connectivity Table 1-1 1-6 Introduction Description of Mini-GBICs Mini-GBIC Specification MGBIC-LC01 Provides one 1000BASE-SX compliant LC fiber-optic multimode port and a standard LC connector. For optical and operating range specifications, refer to “MGBIC-LC01/MGBIC-MT01 Specifications (1000BASE-SX)” on page A-4. MGBIC-LC03 Provides one 1000BASE-SX compliant LC fiber-optic multimode port with a standard LC duplex connector.
Management Management Management of the module can be either in‐band or out‐of‐band. In‐band remote management is possible using Telnet, Enterasys Networks’ NetSight® management application, or the WebView application. Out‐of‐band management is provided through the DB9 Console port connector on the front panel using a VT100 terminal or a VT100 terminal emulator.
Getting Help Getting Help For additional support related to the switches or this document, contact Enterasys Networks using one of the following methods: World Wide Web www.enterasys.com/services/support/ Phone 1-800-872-8440 (toll-free in U.S. and Canada) or 1-978-684-1000 For the Enterasys Networks Support toll-free number in your country: www.enterasys.com/services/support/contact/ Internet mail support@enterasys.com To expedite your message, type [SWITCHING] in the subject line.
2 Network Requirements Before installing the device, review the requirements and specifications in this chapter concerning the following: For information about... Refer to page... 10BASE-T Network 2-1 100BASE-TX Network 2-2 1000BASE-FX Network 2-2 1000BASE-T Network 2-2 Note: The network installation must meet the requirements described in this chapter to ensure satisfactory performance of this equipment. Failure to do so will produce poor network performance.
100BASE-TX Network 100BASE-TX Network When connecting a 100BASE‐TX segment to one of the fixed ports (1 through 24 on B2G124‐24, 1 through 48 on B2G124‐48, or 1 through 48 on B2H124‐48), use Category 5 UTP cabling. The switch at the other end of the twisted pair segment must meet IEEE 802.3‐2002 100BASE‐TX Fast Ethernet network requirements for the switches to operate at 100 Mbps.
3 Hardware Installation Electrical Hazard: Only qualified personnel should perform installation procedures. Riesgo Electrico: Solamente personal calificado debe realizar procedimientos de instalacion. Elektrischer Gefahrenhinweis: Installationen sollten nur durch ausgebildetes und qualifiziertes Personal vorgenommen werden. Important Notice Read the Release Notes shipped with the switch to check for any exceptions to the supported features and operation documented in this guide.
Considerations Prior to Installation Considerations Prior to Installation When installing the switch, note the following: • Before starting the installation procedure, notify the network administrator of the installation. • Follow the installation procedures in the order as presented in this guide. • Do not connect the switch to the network until you have established the correct IP address. Required Tools A Phillips screwdriver is required to install the switch into a rack.
Installing Optional Mini-GBICs Installing Optional Mini-GBICs This section describes how to install Mini‐GBICs in any of the SFP port slots (21 through 24 of B2G124‐24; 45 through 48 of B2G124‐48, or 49 through 52 for B2H124‐48). It is recommended that the options be installed first in a new installation. Warning: Fiber-optic Mini-GBICs use Class 1 lasers. Do not use optical instruments to view the laser output. The use of optical instruments to view laser output increases eye hazard.
Installing Optional Mini-GBICs Installation To install a Mini‐GBIC that has an MT‐RJ connector, refer to Figure 3‐1, or for a Mini‐GBIC with an LC connector, refer to Figure 3‐2, and proceed as follows: 1. Hold the Mini‐GBIC with the top side positioned as shown, and the 7‐pin edge connector facing the port slot. 2. Align the Mini‐GBIC with the port slot. 3. Push the Mini‐GBIC into the port slot until the Mini‐GBIC “clicks” and locks into place.
Installing Optional Mini-GBICs Figure 3-2 Mini-GBIC with LC Connector 21 22 21 23 22 24 23 B2 G1 24 Á Ä Å Â 24 -24 Ã À 1 Mini-GBIC (MGBIC-LC01 or MGBIC-LC09) 2 Mini-GBIC, top side 3 7-pin edge connector (insertion side) 4 Port slot 5 Protective dust cover 6 Release tab Removing the Mini-GBIC Caution: Do NOT remove a Mini-GBIC from a slot without releasing the locking tab located under the front bottom end of the Mini-GBIC. This can damage the Mini-GBIC.
Installing the Switch on a Flat Surface 3. Locate the release tab under the front end of the Mini‐GBIC. For the type of Mini‐GBIC shown in Figure 3‐1, push in on the release tab as far as it will go to release the Mini‐GBIC from the port slot. For the type of Mini‐GBIC shown in Figure 3‐2, pull out on the release tab to release the Mini‐GBIC from the port slot. 4. Grasp the sides of the Mini‐GBIC and pull it straight out of the port slot.
Installing the Switch on a Flat Surface Figure 3-3 Chassis Bottom, Rubber Feet Placement Á À Â Â Â Â 1 Bottom of chassis as seen when chassis is 3 Rubber feet with adhesive backing resting on its back (four) 2 Locations to install the rubber feet (four locations) 4. Remove the protective strip from the back of one rubber foot and position it on a marked location and press firmly into place. Repeat this procedure to install the remaining three rubber feet in the other three locations. 5.
Installing the Switch on a Flat Surface Guidelines for Flat Surface Installation Locate the switch within 152 cm (5 ft) of its power source and on a surface as shown in Figure 3‐4. If an optional redundant power system is going to be installed and connected to the 14‐pin Redundant Power Supply input connector on the rear of the switch, refer to the installation guide shipped with the redundant power system. Caution: To ensure proper ventilation and prevent overheating, leave a minimum clearance space of 5.
Rack Mounting the Switch Rack Mounting the Switch To install the switch in a 19‐inch rack, you need: • Two rackmount brackets and mounting screws (rackmount kit) shipped with the switch. • Four user‐supplied screws to attach the switch to a standard 19‐inch rack. Guidelines for Rackmount Installation The installation site must be within reach of the network cabling and meet the requirements listed below: • Appropriate grounded power receptacles must be located within 152 cm (5 ft) of the location.
Connecting High-Speed Stacking Cables Figure 3-5 Attaching the Rackmount Brackets 1 2 3 4 5 6 7 8 9 10 11 12 13 11 1 14 15 16 17 18 19 20 21 22 23 24 13 21 22 21 22 23 C2G124-24 B2G124-24 24 23 MGR Console RPS UP CPU 12 2 Á 14 24 24 À À 1 Rackmount brackets 2. 23 DOWN Á 2 M3x6 mm flathead screws With the mounting brackets attached, position the switch between the vertical frame members of the 19‐inch rack as shown in Figure 3‐6.
Connecting High-Speed Stacking Cables The high‐speed stacking cables are optional items and must be ordered separately. The B2G124‐48 and B2H124‐48 support three types of SecureStack stacking cables: • C2CAB‐SHORT cable to connect two adjacent switches in the stack. If the stack is in a configuration where the adjacent switches are too far apart for the SHORT cables, the LONG cable can be used for the connections. • C2CAB‐LONG cable to connect from the top switch to the bottom switch in the stack.
Configuring Switches in a Stack Figure 3-7 High-Speed Stacking Cable Connections Redundant Power Supply STACK UP AC LINE 100-240 VAC 50-60 Hz 0.8 A MAX STACK DOWN MAC ADDRESS Â À Â SERIAL NO. Ã Redundant Power Supply STACK UP AC LINE 100-240 VAC 50-60 Hz 0.8 A MAX STACK DOWN MAC ADDRESS Â À Â Á SERIAL NO. À Redundant Power Supply STACK UP AC LINE 100-240 VAC 50-60 Hz 0.8 A MAX STACK DOWN MAC ADDRESS Â À Â SERIAL NO.
Configuring Switches in a Stack Once installed in a stack, the switches behave and perform as a single switch. As such, you can start with a single switch and add more switches as your network expands. You can also mix different products in the family in a single stack to provide a desired combination of port types and functions to match the requirements of individual applications. In all cases, a stack of switches performs as one large product, and is managed as a single network entity.
Configuring Switches in a Stack Recommended Procedures for New and Existing Stacks Important The following procedures assume that all switches have a clean configuration from manufacturing. When adding a new switch to an already running stack, it is also assumed that the new switch is using the same firmware image version as other switches in the stack. Installing a New Stackable System of Up to Eight Switches Use the following procedure to install a new stack of up to eight switches out of the box.
Connecting AC and RPS-SYS Power Adding a New Switch to an Existing Stack Use the following procedure to install a new switch to an existing stack configuration. This procedure assumes that the new switch being added has a clean configuration from manufacturing and is running the same firmware image version as other switches in the stack. 1. Ensure that power is off on the new switch being installed. 2. Use one of the following methods to complete the stack cable connections: 3.
Connecting AC and RPS-SYS Power Figure 3-8 Switch Rear View ST AC K UP ST AC K DO WN AC 10 LIN 0-2 50 40 E 0.8 -60 VAC Hz A MA X MAC ADD RES S SER IAL Re du NO. nd an t Po we r Su pp  Á 10AC L 0- IN 50240 E 0.8 -60 VAC A MHz AX À 1 AC power cord 3. ly 2 AC power connector 3 Connector for external redundant power supply Observe that the power CPU LED (not shown), located on the front panel.
Connecting AC and RPS-SYS Power C2RPS-SYS Redundant Power System If you are installing an optional redundant power system (C2RPS‐SYS), refer to the installation instructions supplied with the SecureStack RPS. The switch is connected to a C2RPS‐PSM using a C2RPS‐PSM Cable. Caution: To prevent damaging the switch, DO NOTconnect a Power over Ethernet-compliant Redundant Power System (C2RPS-POE) to the redundant power supply connector.
Connecting to Console Port for Local Management Connecting to Console Port for Local Management This section describes how to install an RS232 DTE interface cable to a PC, a VT series terminal, or a modem to a SecureStack B2G124‐24, B2G124‐48, or B2H124‐48 for out‐of‐ band sessions using CLI commands.
Connecting to Console Port for Local Management Figure 3-9 DB9 Male Console Port Pinout Assignments  5 Á À 1 9 1 2 3 Pin 2, Received Data (input) Pin 3, Transmitted Data (output) Pin 5, Signal Ground All other pins not connected. 6 Connecting to an IBM or Compatible Device To connect an IBM PC or compatible device, running the VT terminal emulation, to an Enterasys switch Console port (Figure 3‐10), proceed as follows: 1.
Connecting to Console Port for Local Management Figure 3-10 Connecting an IBM PC or Compatible Co ns ole MG R RP S CP Ä Á Ã 1 DB9 female connector 2 Serial interface cable 3 DB9 male Console port connector À U UP DO WN Â 4 DB9 female connector 5 PC with VT emulation application Connecting to a VT Series Terminal To connect a VT Series terminal to an Enterasys switch Console port (Figure 3‐11), use a UTP serial interface cable terminated with a DB9 female connector and a DB25 female connect
Connecting to Console Port for Local Management Figure 3-11 Connecting a VT Series Terminal Co ns ole MG R RP CP Ä 1 DB9 female connector 2 Serial interface cable 3 DB9 male Console port connector à Á À U S UP DO WN  4 DB25 female connector 5 PC with VT emulation application Connecting to a Modem To connect a modem to an Enterasys Networks switch modem port (Figure 3‐12), use a UTP cable terminated with a DB9 female connector and a DB25 male connector, and proceed as follows: 1.
Connecting to the Network Figure 3-12 Connecting to a Modem Co ns ole MG R RP S CP U Æ Å Ä Ã 1 DB9 female cable connector 2 Serial interface cable 4 DB25 male connector 5 Local modem 3 DB9 male Console port 6 Remote modem Á À UP DO WN Â 7 PC with VT emulation application Connecting to the Network The following procedures cover the cable connections from the network or other devices to the switch RJ45 ports or any installed optional Mini‐GBIC.
Connecting to the Network 2. Connect the twisted pair segment to the switch by inserting the RJ45 connector on the twisted pair segment into the desired RJ45 port (for example, Port 8). Figure 3-13 Connecting a UTP Cable Segment to RJ45 Port  1 1 2 3 4 5 6 7 8 9 2 10 11 12 À Á 11 12 1 RJ45 connector 2 Port 8 3. 3 Port 8 Link/Activity LED Verify that a link exists by checking that the Link/Activity LED is ON (solid green or blinking green).
Connecting to the Network Figure 3-14 Four-Wire Crossover Cable RJ45 Pinouts for 10/100BASE-TX À Á RX+ 1 1 RX+ RX 2 2 RX TX+ 3 3 TX+ TX 6 6 TX Ã Â 1 RJ45 switch port 2 Other device port Figure 3-15 3 RJ45-to-RJ45 crossover cable 4 RX+/RX- and TX+/TX-connections These connections must share a common color pair.
Connecting to the Network Figure 3-16 Eight-Wire Crossover Cable RJ45 Pinouts for 10/100/1000BASE-TX À Á TX1+ 1 1 TX2+ RX1- 2 2 RX2- TX2+ 3 3 TX1+ TX3+ 4 4 TX4+ RX3- 5 5 RX4- RX2- 6 6 RX1- TX4+ 7 7 TX3+ RX4- 8 8 RX3- Â 1 RJ45 device port 2 Other device port 3 RJ45-to-RJ45 crossover cable Figure 3-17 Eight-Wire Straight-Through Cable RJ45 Pinouts for 10/100/ 1000BASE-TX À Á TX1+ 1 1 TX2+ RX1- 2 2 RX2- TX2+ 3 3 TX1+ TX3+ 4 4 TX4+ RX3- 5 5 RX4- RX2-
Connecting to the Network Connecting Fiber-Optic Cables to MT-RJ Ports Warning: Fiber-optic Mini-GBICs use Class 1 lasers. Do not use optical instruments to view the laser output. The use of optical instruments to view laser output increases eye hazard. When viewing the output optical port, power must be removed from the network adapter. Advertencia: Los Mini-GBICS de fibra optica usan lasers de clase 1. No se debe usar instrumentos opticos para ver la potencia laser.
Connecting to the Network . Caution: Do not touch the ends of the fiber-optic strands, and do not let the ends come in contact with dust, dirt, or other contaminants. Contamination of cable ends causes problems in data transmissions. If the ends of the fiber-optic strands become contaminated, use a canned duster to blow the surfaces clean. A fiber-port cleaning swab saturated with optical-grade isopropyl alcohol may also be used to clean the ends.
Connecting to the Network b. If there are separate fiber‐optic connections on the other device, check the crossover of the cables. Swap the cable connections if necessary. c. Check that the fiber‐optic connection meets the dB loss and cable specifications outlined in the Cabling Guide for multimode cabling. To obtain this document, refer to “Related Documents” on page xvi. If a link has not been established, refer to Chapter 4 for LED troubleshooting details.
Connecting to the Network To connect an LC cable connector to a fixed LC connector of a Mini‐GBIC, refer to Figure 3‐19 and proceed as follows: Caution: Do not touch the ends of the fiber-optic strands, and do not let the ends come in contact with dust, dirt, or other contaminants. Contamination of cable ends causes problems in data transmissions. If the ends of the fiber-optic strands become contaminated, use a canned duster to blow the surfaces clean.
Connecting to the Network Figure 3-19 Cable Connection to LC Fiber-Optic Connectors 21 Ã 22 21 23 22 24 23 Â B2 G1 24 24 -24 À Á 1 Mini-GBIC MT-RJ port connector 2 LC cable connector 3 Release tab 4 Link/Activity LED 3. Plug the other end of the cable into the appropriate port on the other device. Some cables may be terminated at the other end with two separate connectors, one for each fiber‐optic strand.
Completing the Installation Completing the Installation After installing the switch and making the connections to the network, access the switch management, as described below. Initial Logon to Switch Management To initially access switch management from your local PC, terminal, or modem connection, proceed as follows at the displayed startup screen: 1. Enter rw (Read‐Write) for Username. 2. At the Password prompt, press Enter (RETURN). 3.
Completing the Installation 3-32 Hardware Installation
4 Troubleshooting This chapter provides information concerning the following: For information about... Refer to page... Using LANVIEW 4-2 Troubleshooting Checklist 4-6 Using the Reset Switch 4-8 This device contains a battery that is not considered a user replaceable part. If the battery needs to be replaced, contact customer service for repair. Caution: There is a risk of explosion if the battery is replaced with an incorrect type. A used battery may be safely disposed in a municipal waste stream.
Using LANVIEW Using LANVIEW These switches support the Enterasys Networks built‐in LANVIEW LED visual diagnostic and status monitoring system. The LANVIEW LEDs on both the B2G124‐24 and B2G124‐48 are located in similar locations as shown on B2G124‐24 in Figure 4‐1. The LANVIEW LEDs on the B2H124‐48 are shown in Figure 4‐2. These LEDs allow you to quickly observe network status for diagnosing switch and network problems.
Using LANVIEW Figure 4-2 LANVIEW LEDs of B2H124-48 Æ Å 1 2 3 4 5 6 7 8 9 10 11 1 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 Ç 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 15 17 31 33 47 16 18 32 34 48 50 51 52 49 51 50 52 B2H124-48 MGR RPS UP DOWN CPU 2 MGR RPS UP CPU 1 2 3 4 5 DOWN Console Ä Ã Â Á À CPU LED STACK DOWN LED STACK UP LED RPS LED for redundant power source status Manager LED 6 Link/Acti
Using LANVIEW Table 4-1 LANVIEW LEDs LED Color State Recommended Action CPU Off Power disconnected. If the LED remains off after connecting AC power or DC power from an RPS, check the following: 1. Make sure there is power at the power source (AC source and RPS if applicable). 2. Replace the power cord with a known good one or check the continuity of the power cord. 3. If the switch still does not power up, the system may have a fatal error. Contact Enterasys Networks for technical support.
Using LANVIEW Table 4-1 LANVIEW LEDs (continued) LED Color State Recommended Action UP Off No valid connection to switch stackdown connector. 1. Make sure the switch connected to the stackdown connector is powered on. 2. Replace cable with a known good one. 3. If the problem still exists, contact Enterasys Networks for technical support. Green Solid. Valid connection to switch stackdown connector. None. Blinking. Information is being transferred via the high-speed stacking cable.
Troubleshooting Checklist Table 4-1 LANVIEW LEDs (continued) LED Color State Recommended Action Link/ Activity Off 1. No link. None. 2. No activity or port in standby. None. 3. If the port is one of the highest numbered last four RJ45 ports, the port is deactivated because the Mini-GBIC port with the same port number is linked. None. 4. If the port is a Mini-GBIC port, the port is deactivated because the RJ45 port with the same port number is linked. None. Solid.
Troubleshooting Checklist Table 4-2 Troubleshooting Checklist (continued) Problem Possible Cause Recommended Action Cannot navigate beyond startup screen. Improper Community Names Table. Refer to the SecureStack B2 Configuration Guide for the Community Names Table setup. Cannot contact the switch through inband management. IP address not assigned. Refer to the SecureStack B2 Configuration Guide for the IP address assignment procedure. Port is disabled.
Using the Reset Switch Using the Reset Switch If you forget the switch login password, use the Reset switch as described in the following procedure. Figure 4-3 Reset Switch ST AC K UP ST AC K DO WN À 1 Reset switch To reset the switch password, refer to Figure 4‐3 and proceed as follows: Note: Notify the system manager before changing the password. 1. Press‐and‐hold the Reset switch while the switch is operational.
A Specifications This appendix provides information about the following: For information about... Refer to page... Switch Specifications A-1 Mini-GBIC Input/Output Specifications A-4 Gigabit Ethernet Specifications A-4 MGBIC-02 Specifications (1000BASE-T) A-7 Regulatory Compliance A-8 Enterasys Networks reserves the right to change the specifications at any time without notice.
Switch Specifications Table A-1 Switch Specifications (continued) Item Specification B2G124-48 RJ45 ports 1 through 48 Forty-eight, 10BASE-T/100BASE-TX/1000BASE-T compliant ports with auto-sensing and auto-negotiation through the RJ45 connections. SFP ports 45 through 48 Four slots that support optional Mini-GBICs for 1000BASE-FX fiber-optic connections and 1000BASE-T copper connections.
Switch Specifications Table A-1 Switch Specifications (continued) Item Specification Predicted hours for Mean Time Between Failures (MTBF) For the MTBF hours for these products, refer to the MTBF web site at URL http://www.enterasys.com/support/mtbf/ Heat Dissipation (maximum) B2G124-24 B2G124-48 B2H124-48 @ 86.40 W, 294.80 Btu/hr @ 129.50 W, 441.87 Btu/hr @ 65.50 W, 205.80 Btu/hr AC Input Specifications Input Voltage 100 to 240 VAC Input Current B2G124-24 0.8 A Max B2G124-48 1.
Mini-GBIC Input/Output Specifications Mini-GBIC Input/Output Specifications The Mini‐Gigabit Ethernet Card (Mini‐GBIC) port interface slots can support 1‐Gbps fiber‐optic connections as described in Table A‐2. The optional Mini‐GBICs are hot swappable. Table A-2 Mini-GBIC Input/Output Port Specifications Item Specification MGBIC-LC01 Provides one LC fiber-optic multimode port that is compliant with the 1000BASE-SX standard LC connector.
Gigabit Ethernet Specifications Table A-4 MGBIC-LC01/MGBIC-MT01 Operating Range Item Modal Bandwidth @ 850 nm Range 62.5 µm MMF 160 MHz/km 2-220 Meters 62.5 µm MMF 200 MHz/km 2-275 Meters 50 µm MMF 400 MHz/km 2-500 Meters 50 µm MMF 500 MHz/km 2-550 Meters MGBIC-LC03 Specifications (1000BASE-SX) Table A-5 MGBIC-LC03 Optical Specifications Item 62.5/125 µm MMF 50/125 µm MMF Transmit Power (minimum) -9.5 dBm -9.
Gigabit Ethernet Specifications MGBIC-LC09 Specifications (1000BASE-LX) Table A-7 MGBIC-LC09 Optical Specifications Item 62.5 µm MMF 50 µm MMF 10 µm SMF Transmit Power (minimum) -11.5 dBm -11.5 dBm -9.5 dBm Receive Sensitivity -20 dBm -20 dBm -20 dBm Link Power Budget 8.5 dBm 8.5 dBm 10.5 dBm Table A-8 MGBIC-LC09 Operating Range Item Modal Bandwidth @ 1300 nm Range 62.
Console Port Pinout Assignments MGBIC-02 Specifications (1000BASE-T) Table A-11 MGBIC-02 Specifications Item Specification Supported Cable: Type Copper, Category 5 UTP Maximum Length Up to 100 meters Connector RJ45 Data Rate 1 Gbps, IEEE 802.
Regulatory Compliance Regulatory Compliance The B2G124‐24, B2G124‐48, and B2H124‐48 meet the safety and electromagnetic compatibility (EMC) requirements listed in Table A‐12: Table A-12 A-8 Specifications Compliance Standards Regulatory Compliance Standards Safety UL 60950, CSA C22.2 No. 60950, 73/23/EEC, EN 60950, and IEC 60950. The Mini-GBICs that support laser connections also meet the EN 60825 and 21 CFR 1040.10 standards. Electromagnetic Compatibility (EMC) 47 CFR Parts 2 and 15, CSA C108.
