Memory Locations and Replacement Procedures
B-2 Mode Switch Bank Settings and Optional Installations
•Switch7ClearPersistentData.ChangingthepositionofthisswitchclearsPersistentDataon
thenextpowerupofthemodule.Alluserenteredparameters,suchastheIPaddress,module
names,etc.,areresettothefactorydefaultsettings.Oncethemoduleresets,youcaneitheruse
the
factorydefaultsettingsorreenteryourownparameters.
•Switch8ClearAdminPassword.Changingthepositionofthisswitchclearstheadmin
password,andrestoresthefactorydefaultpasswordonthenextpowerupofthemodule.
Oncethemoduleresets,youcaneitherusethefactorydefaultsettingsor
reenteryourown
password.
Memory Locations and Replacement Procedures
IntheeventthattheDIMM(DualInlineMemoryModule)orDRAMSIMM(DRAMSingleIn
lineMemoryModule)(FLASHmemory)needstobe replaced,thefollowingsectionsdescribe
howtoaccess,locateandrep lacethesememorymodules.Ifyouhavequestionsconcerningthe
replacementofeithermemorymodule,refer
toGettingHelponpagexivfordetailsonhowto
contactEnterasys Networks.
Note: Do not change the position of Switch 8 unless it is necessary to reset the admin password to
its factory default setting.
Figure B-1 Mode Switch Location
1 Mode switch bank
