Memory Locations and Replacement Procedures
B-4 Mode Switch Bank Settings and Optional Installations
3. PulltheDRAMSIMMstraightupandremoveitfromtheconnectorfingers.
Installing the DRAM SIMM
ToinstallaDRAMSIMM,refertoFigure B‐4andproceedasfollows:
1. PushtheconnectorarmsawayfromtheDRAMSIMMenoughtoinserttheDRAMSIMMinto
theconnectorfingers.
2. InserttheDRAMSIMMstraightdownbetweentheconnectorfingersenoughforthetabson
theconnectorarmstoalign
withthetwoDRAMSIMMalignmentnotches.
3. PushtheDRAMSIMMdownintothe connectorfingers.Thenrotatethetwoconnectorarms
towardtheDRAMSIMMtolockitintoplace.
Figure B-3 Removing the Existing DRAM SIMM
1 Connector arms 2 DRAM SIMM 3 Connector fingers
Á
Â
À
À
Caution: Observe all Electrostatic Discharge (ESD) precautions when handling sensitive electronic
equipment.
Precaución: Al trabajar con equipos electrónicos sensibles, tome todas las precauciones de
seguridad para evitar descargas de electricidad estática.
