BASIC NETWORK SETTINGS CONFIGURING ADVANCED SETTINGS
ESR600H/ESR750H 6-45 USER GUIDE
6.4.2 Configuring Advanced Settings
Advanced settings parameters available on the router.
WARNING!
Incorrectly changing these settings may cause the device to stop functioning. Do not modify the settings in this
section without a thorough understanding of the parameters.
Fragment Threshold Enter the maximum size of a
packet during data transmission. A value too low could
lead to low performance.
RTS Threshold Enter the RTS threshold. If the packet
size is smaller than the RTS threshold, the ESR600H/
ESR750H will not use RTS/CTS to send the data packet.
Beacon Interval Enter the beacon interval. This is the
amount of time that the ESR600H/ESR750H will synchro-
nize the network.
Delivery Traffic Indication Message (DTIM) Period
Enter the DTIM period. The DTIM is a countdown period
informing clients of the next point of broadcast and multi-
cast of messages over the network. Valid values are
between 1 and 255.
!
