ENGENIUS QUICK START CONNECTING NETWORK CABLES
ESR600H/ESR750H 3-3 USER GUIDE
3.2 Connecting Network Cables
CAUTION!
Unplug all peripherals and the router’s adapter before starting with this procedure.
1. Connect the adapter cable to an electrical outlet.
Note:
The Power LED lights up to show the device is active.
2. Plug one end of the Ethernet cable (1) into the WAN port
on the back panel of the router. Plug the other end of the
cable into the cable or DSL modem.
!
Power LED
