INSTALLATION WALL MOUNTING
ESR600H/ESR750H 2-2 USER GUIDE
2.2 Wall Mounting
Mounting the ESR600H/ESR750H on a wall optimizes the wireless access range.
To mount the device on the wall do the following:
1. Measure the distance from the middle of each mounting screw hole.
2. Mark the locations of the screw holes on the wall.
3. Drill a hole for each marked location and insert a screw in each.
4. Install and secure the mounts onto the ESR600H/ESR750H.
5. Install the ESR600H/ESR750H on the wall.
Note:
Choose a location that is within reach of an electrical outlet for the AC adapter and the DSL or Cable modem.
Note:
Make sure to leave enough of the screw head above the wall surface to secure the router.
