PRODUCT OVERVIEW PRODUCT LAYOUT
ESR600H/ESR750H 1-5 USER GUIDE
FRONT PANEL COMPONENTS DESCRIPTION
WPS/Reset Button
Wi-Fi Protected Setup button.
To activate 2.4G WPS, press button for 0~5 seconds.
To activate 5G WPS, press button for 5~10 seconds.
N/A 10~15 seconds
To reset to factory settings, press button for > 15 seconds.
Power LED
Power status LED.
WLAN LED
Wireless LAN (WLAN) status LED.
WAN LED
Network status LED.
LAN (1 – 4) LEDs
LAN port status LED(s).
