Installation manual

14
glass are maintained at hot. To clean the glass, there are a number of specially designed
cleaners. Your authorized Enerzone dealer can recommend a suitable cleaner which is
available in your area. Regular household glass cleaners will not clean creosote. Do not use
abrasives such as steel pads, steel wool or oven cleaner as they will scratch the glass. Only
wash when the stove is cold.
3.3.10 Gasket Replacement
Remove the doors from the unit and lay them on a clean, unabrasive surface. To replace the
gasket around the door frame, first remove the old gasket and adhesive. Make sure that the
surface is totally clean before applying new adhesive (a high temperature silicone caulking
rated for at least 500ºF, 260ºC, is suitable) or adhesion problems may result. Apply the
adhesive inside the door groove (gasket channel) and install the new gasket with a gentle
pressure. Let dry for at least 24 hours. To replace the glass gasket, simply remove the glass
retainers holding the glass to the door frame. Remove the glass and peel off the gasket
surrounding it. Replace it by a new, self-adhesive glass gasket. The proper replacement
gaskets are available from your Enerzone dealer in the following dimensions:
Gasket Length Dimensions
Around each glass 51 ½" (131 cm) U SHAPE
On each door frame 41 ¼" (105 cm) Flat ¼" x ½"
Along the door joint 14" (36 cm) Flat ¼" x ½"
