Figure 7. RF Combiner Rear Panel.
The RF Combiner is installed at the Hub and accommodates two BTS inputs.
2.0 Installation Guide
The following guidelines provide a step by step installation procedure which should
be followed closely to insure a successful deployment.
2.1 Shipment Contents
The following items should be included with each EkoLite II Shipment:
Hub(s)
Remotes(s)
User manual (this document)
Software Command Reference Manual
AC Power supply (optional)
2.2 Site Selection
2.2.1 Hubs
The Hub(s) should be located as close as possible to the donor BTS. Observe all
environmental specifications for the hub to avoid damage from moisture, heat, cold,
etc.
2.2.2 Remotes
Ensure that each remote location is correct according to the system design
drawings. Observe all environmental specifications for the remote to avoid
damage from moisture, heat, cold, etc.
