2. Any existing alarm messages (from factory testing and initialization) should be
cleared before activating the repeater. First check the existing alarm log, then clear
the log. This can be done at any time during the setup procedure.
LOG <enter>
CLEAR LOG <enter>
3. The proper communication mode must first be enabled before communications can
begin. For DataCall messaging:
SET DEV DTC <enter>
4. The phone number to which the repeater will report alarms must be programmed into
the repeater, using the following command:
SET ASC [phone number] <enter>
5. Set the maximum number of times (Maximum Number of Repetitions) the repeater
will attempt to resend an unacknowledged message to the predetermined phone
number:
SET MNR xx <enter>
where xx = number of retries.
6. Set the amount of time the repeater should wait (Repetition Cycle Alarm) for an
acknowledgment before resending the messaging, preset at 10 minutes.
SET RCA xxx <enter>
where xxx is the number of minutes to wait between each retry.
7. To set the Repeater’s ID number:
SET RID xx-yy-zzzz <enter>
where x, y, and z are digits.
8. The threshold for Illegal Login Attempts tells how many times a false password can
be attempted before the systems locks out any further attempts. This is preset at 8.
To reset the value,
SET ILA xx <enter>
9. The external alarms can be configured active low or active high, so that the alarm is
given in either the presence or absence of applied power.
SET EXT BC <enter>
Where B, read from EX1, refers to pin 1 and C, read from EX2, refers to
pin 2.
