6.12 Heartbeat Message Format
Field Format Description
Repeater ID XX-YY-ZZZZ
Message no. NNNNN
State STATE Incoming heartbeat
Date DDMMYY
Time HHMMSS 24 hour clock
NCH N Number of channels
CHA 1 NNN If channel is not installed, number is replaced by '-' Length of
attribute depends on channel number (ie, CDMA channel 100)
CHA2 NNN If channel is not installed, number is replaced by '-' Length of
attribute depends on channel number (ie, CDMA channel 100)
Reserved for - - Two dashes separated by a space
future use
ATU1 NN If channel is not installed, number is replaced by '-' (dash)
ATU2 NN If channel is not installed, number is replaced by '-' (dash)
Reserved for - - Two dashes separated by a space
future use
ATD1 NN If channel is not installed, number is replaced by '-' (dash)
ATD2 NN If channel is not installed, number is replaced by '-' (dash)
Reserved for - - Two dashes separated by a space
future use
LVU1 NN If channel is not installed, number is replaced by '-' (dash)
LVU2 NN If channel is not installed, number is replaced by '-' (dash)
Reserved for - - Two dashes separated by a space
future use
LVD1 If channel is not installed, number is replaced by '-' (dash)
LVD2 If channel is not installed, number is replaced by '-' (dash)
Reserved for - - Two dashes separated by a space
future use
SZU BB If status not available, replaced by '-'
SZD BB If status not available, replaced by '-'
AMU BB If status not available, replaced by '-'
AMD BB If status not available, replaced by '-'
COM BBBB If status not available, replaced by '-'
TEM B State of temperature
DOO B State of door
PW1 B State of power 1
PW2 B State of power 2
EX1 B State of external pin 1
EX2 B State of external pin 2
RCH NNNN Repetition cycle heartbeat
RCA NNN Repetition cycle alarm
MNR NN Maximum number of alarm repetitions.
