Operator's Manual

CI Wireless Inc. Description of the Control Module
MirrorCell Select CDR812 Manual
Rev. X1 6-15
6.11.7 Miscellaneous Alarm Configuration Parameters
6.11.7.1 Configuring the External Alarms
The external alarms can be configured active-low or active-high. Use the following
command to configure these alarms:
SET EXT BC <enter>
B refers to pin 1, read from EX1, and C refers to pins 2, read from EX2.
B, C = 0 means that no voltage is an OK condition
B, C = 1 means that a high voltage is an OK condition.
Note: The write access to these parameters is valid only if you are logged in with a read-
and-write access password, or if you are sending an SMS message with read and write
access.
Designation Attribute Read Write Format Comments
External alarm EXT X X BC B, C = 0 Alarm active low.
pin configuration B, C = 0 Alarm active high.
Repetition cycle RCA X X NNN Amount of time the repeater waits before
alarm 3 digits retransmitting unconfirmed alarm
Minimum alarm MAR X X NN NN is from 0 to 99 minutes.
repetition time 2 digits
Maximum MNR X X NN Maximum number of RCA attempts.
number of 2 digits
repetitions
