6.11.6.2 Alarm Threshold Values
Alarm Send Ack Eval Lower Upper Seconds Comments
Code
SZU 0 0 4 000 000 001
SZD 0 0 4 000 000 001
AMU 0 0 2 020 000 001
AMD 0 0 2 020 000 001 Set for 33 dBm output
TEM 0 0 3 000 060 005
Threshold in ° C
DOO 0 0 4 000 000 030
PW1 0 0 1 090 110 005 Threshold in % of normal
PW2 0 0 1 090 110 005 Threshold in % of normal
EX1 0 0 4 000 000 001
EX2 0 0 4 000 000 001
COM 0 0 4 000 000 001
VLI 0 0 4 000 000 000
LGO 0 0 4 000 000 000
CLR 0 0 4 000 000 000
ILI 0 0 4 000 000 000
Example of an alarm string custom configuration, with message fields separated by
blanks:
SET ALA PW1 0 0 1 80 120 5 <enter>
will customize the thresholds for the PW1 alarm. It will enable the alarm, require
acknowledgment, set the lower threshold to 80, set the upper threshold to 120, and
require the attribute to be out of limits for 5 seconds before an alarm is generated. The
alarm evaluator remains in the default value (1).
Note: The threshold for the AMD alarm depends upon the output power. The default of
“20” is based on a peak output power of 33dBm. For output power = 30, set AMD to 17.
For output power = 27, set AMD to 14.
