6.11.4 Acknowledgment of Alarms
In the case of DataCall communications, the alarm is considered to be acknowledged
when the repeater has logged in to the OMC and reports the alarm.
Message Field Format Description
Repeater ID XX-YY-ZZZZ ID of the repeater that the message is intended for.
Message number NNNNN Message number from the OMC.
Command ACT Indicates that the message will perform an action.
Argument ACK Indicates that an acknowledgment is expected.
Argument MMMMM Message number of the alarm/end alarm message
sent by the repeater.
An example of an alarm acknowledgment message, with message fields separated by
blanks:
17-42-4711 00242 ACT ACK 00023
This message indicates an acknowledgment of alarm number 00023 from repeater 17-
42-4711.
6.11.5 Alarm Re-transmission
If the repeater fails to send an alarm, or of it does not receive an acknowledgment of the
alarm, the repeater will attempt to re-send the alarm after a user-configurable time
interval. The repeater will continue to try to re-send the alarm for a user-configurable
number of times, or until the repeater receives an acknowledgment of the alarm.
The command/attribute for setting the time interval between re-transmissions (Repetition
Cycle Alarm) is:
SET RCA XXX <enter> (0<XXX<999 minutes)
The command/attribute for setting the maximum number of repetitions, MNR, is:
SET MNR XX <enter> (0<XX<99 repetition)
