6.11.3 Alarm Attributes
The following table provides a description of each of the alarm sources within the
repeater and the corresponding severity levels and class. In the parameter field, X = 0
means the attribute if OK, and X = 1 means the attribute is in error. Some of the attributes
have the capability to report “-“ which indicates the piece of equipment that would
normally report this alarm is not installed. For example, in a two channel repeater with
only one channel installed, certain alarms for channel 2 will indicate “-“.
Alarm Severity Class Parameter Description and notes
attribute Alarm/End
SZU CR/CL EQ XX Synthesizer uplink (reverse)
UL1 and UL2 status reported.
SZD CR/CL EQ XX Synthesizer downlink (forward)
DL1 and DL2 reported.
AMU CR/CL EQ XX Uplink amplifier chain for UL1 and UL2.
AMD CR/CL EQ XX Downlink amplifier chain for DL1 and DL2.
TEM CR/CL EQ XX Temperature alarm.
DOO CR/CL EQ XX Door alarm.
PW1 CR/CL EQ XX Power 1 alarm.
PW2 CR/CL EQ XX Power 2 alarm.
EX1 WA/CL EN XX Alarm from external pin 1.
EX2 WA/CL EN XX Alarm from external pin 2.
COM WA/CL EN XYZW Communication between controller and
channelizers. The order is:
X: UL1, Y: UL2, Z: DL1, W: DL2.
VLI WA EN [Username] Valid login alarm; an alarm that someone has
logged in successfully to the repeater.
Username is the username logged in.
NOTE: No end of alarm message sent.
LGO WA EN [Username] Sent to indicate that Username has logged out
from the repeater.
NOTE: No end of alarm message sent.
CLR MI EN Sent to indicate that changes were made by
the last person logged in to the repeater.
NOTE: No end of alarm message sent.
ILI CR EN [Username] Sent when the maximum number of failed login
Attempts is exceeded.
[Username] is the last person attempting to login.
NOTE: No end of alarm message sent.
