Operator's Manual

Description of the Control Module CI Wireless Inc.
MirrorCell Select CDR812 Manual
6-8
Rev. X1
6.10.5 Heartbeat Parameter
Designation Attribute Read Write Format Comments
Repetition Cycle RCH X X NNNN Interval between heartbeat messages to
Alarm 0 to 1440 OMC in minutes. Setting RCH to 0
disables heartbeat. When setting this
parameter, a heartbeat will be sent out as
soon as possible (ie, when user logs out
if currently logged in)
6.10.6 Miscellaneous Parameters
Designation Attribute Read Write Format Comments
Date DAT X X DDMMYY
Hardware version HWV X CC..CC Hardware version of the
number (max 120 characters) controller.
Invalid login ILA X X CC Number of consecutive
attempts (2 digits) invalid login attempts before
an alarm is generated. The
number is independent of the
User-ID.
Timeout for LMT LMT X X NN Time after user is
(2 digits) automatically logged out
when no activity is detected.
Maximum Gain MGA X GG GG = maximum gain of the
(2 digits) repeater.
Number of NCH X N Number of channels
channels (1 < N < 4) installed in the repeater.
Repeater RIN X CC..CC Miscellaneous repeater
information (max 120 characters) information.
Serial Number SNO X CC..CC Textual description of
(max 37 characters) repeater and controller
serial numbers.
Software version SWV X CC..CC Version of software in
number (max 120 characters) controller.
Time TIM X X HHMMSS 24 hour clock.
Vendor name VND X CC..CC Vendor information.
(max 120 characters)
