Operator's Manual

CI Wireless Inc. Description of the Control Module
MirrorCell Select CDR812 Manual
Rev. X1 6-7
6.10.3 Communication Parameters
Designation Attribute Read Write Format Comments
Addresses ADD X X N XXXXX..X These addresses are used when the
up to 15 digits repeater is configured for SMS. These are
phone numbers to which the repeater
reports messages;
Up to four numbers are allowed:
N = Selector (1 < N < 4)
Address of OMC ASC X X NNNN..NN For DataCall, address to dial for the OMC.
Up to 15 digits For SMS, address of Short Message
Service Center (SMSC)
Communication DEV X X MMM MMM = DTC for DataCall or remote
Device VT-100 series login capability.
MMM = SMS enables SMS
MMM = NUL disables Communication.
Main Address MAD X X N Used when configured for SMS.
1 < N < 4 Main address is the selector of one of the
four addresses from ADD. This is the
address to which alarms, heartbeat
information, and traffic reports will
be sent.
Modem Connect MCT X X NN 30 to 90 seconds; the time the repeater
Time waits for the modem connection to be
established. Valid only when configured
for DataCall.
Message MSG X X N MMMMMM N = Selector (1 < N < 4)
Numbers Number of messages sent from the
repeater.
6.10.4 Security Parameters
Designation Attribute Read Write Format Comments
OMC to Repeater ORP X XXXXXXXX Up to 8 characters
Password Password used for OMC to login to
the repeater
Passwords PWD X N XXXXXXXX Password up to 8 characters long
N = Selector (1 < N < 4)
Repeater to OMC ROP X XXXXXXXX Password up to 8 characters long
Password Password for repeater to login to OMC
User-ID UID X N XXXXXXXX Password up to 8 characters long
(1 < N < 4) N = Selector (1 < N < 4)
User-ID 1 and 2: read and write
User-ID 3 and 4: read only
