6.10.2 Status Parameters
Designation Attribute Read Write Format Comments
Amplifier downlink AMD X BB First digit: channel 1 status
status Second digit: channel 2 status
0 is OK
1 is ERROR
- is channel not installed
Amplifier uplink AMU X BB First digit: channel 1 status
status Second digit: channel 2 status
0 is OK
1 is ERROR
- is channel not installed
Status of COM X XYZW X is status of communication with
communication channelizer 1 UL (reverse)
Channelizers to Y is status of communication with
Controller channelizer 2 UL (reverse)
Z is status of communication with
channelizer 1 DL (forward)
W is status of communication with
channelizer 2 DL (forward)
0 is OK
1 is ERROR
- is channel not installed
Door status DOO X B 0 = closed; 1 = opened
External pin 1 EX1 X B Status of external pin 1
status 0 is OK
1 is ERROR
External pin 2 EX2 X B Status of external pin 2
status 0 is OK
1 is ERROR
Power 1 status PW1 X B Status of Power 1
0 is OK
1 is ERROR
Power 2 status PW2 X B Status of Power 2
0 is OK
1 is ERROR
Synthesizers SZD X BB First digit: channel 1 status
downlink Second digit: channel 2 status
0 is OK
1 is ERROR
Synthesizers SZU X BB First digit: channel 1 status
uplink Second digit: channel 2 status
0 is OK
1 is ERROR
Temperature TEM X B 0 indicates operating within limits
1 indicates operating out of limits
