6.10 Command Attributes
Note: Write access to the parameters shown in each table is valid only if you have
logged in with a read-and-write access password.
6.10.1 Channel Assignment Parameters
Designation Attribute Read Write Format Comments
Attenuation ATD X X N MM N is the repeater channel number,
Downlink MM is the amount of attenuation
(Forward) between 0 and 30 in 2dB steps.
Attenuation ATU X X N MM N MM N is the repeater channel number,
Uplink MM is the amount of attenuation
(Reverse) between 0 and 30 in 2dB steps.
Channel CHA X X N MMM N MMM N is the repeater channel number,
Information MMM is the actual CDMA channel number.
Channel limits CHL X XXX YYY XXX is the minimum CDMA channel
number.
YYY is the maximum CDMA channel
number.
Output level LVD X X N MM N MM N is the repeater channel number,
Downlink MM is the RF output power limiting
(Forward) point: 27, 30, 33dBm.
Set MM to "1" to disable the amplifier to
turn off the repeater.
Output level LVU X X N MM N MM N is the repeater channel number,
Uplink MM is the RF output power limiting
(Reverse) point: 27, 30, 33dBm; NOTE: due to low
output power from the mobile, reverse
path power rarely exceeds 20dBm.
Set MM to "1" to disable the amplifier to
turn off the repeater.
