The control module logs the number of failed login attempts. If this number exceeds the
user-defined maximum (ILA, default = 8), then future login attempts will be blocked. The
false login count is decreased by one each hour. This means you must wait one hour
after reaching the maximum number of failed login attempts before a single login can be
initiated.
6.4 Commands
The control module does not differentiate between upper- and lower case characters.
Command attributes and parameters can be viewed in the tables in section 6.10.
Available commands:
• ADDRESS Gives information about current address configuration.
• CLEAR Clears the display.
• CLOCK Displays a real-time clock.
• HELP Displays a quick overview of commands.
• LOG Shows the alarm log.
• LOGOUT Ends the work session.
• STATUS Displays the RF parameters (channel number, attenuation,
etc.), as well as peripheral parameters (current draw, status
of door).
• SYSTEM Shows system data (number of messages).
• SET, GET These commands allow the monitoring and control of the
repeater’s parameters.
All user editable parameters and current status of the repeater can be accessed using
the GET and SET commands. Refer to section 6.10 for the format of the different
attributes.
Note: The command field must be completely used; otherwise an error results.
Two parameters are writable only, not readable; these are Username and Password. See
table 6.10.6.
The syntax for the GET command is:
GET [Attribute] <enter>
For example, to get the status of the forward path amplifier chains:
GET AMD <enter>
The syntax for the SET command is:
SET [Attribute] [Format] <enter>
Where all entries must be separated by a blank space. For example, to set the channel
number for the repeater’s channel 1:
