Operator's Manual

Specifications CI Wireless Inc.
MirrorCell Select CDR812 Manual
3-2
Rev. X1
3.2 Mechanical Specifications
Housing (W x H x D) 12 x 17.9 x 9.5 inches
Housing, with metal cover 15.2 x 19.9 x 11.8 inches
and anchorable feet
Weight 47 + 2 pounds, completely loaded
Housing Material Aluminum
Primary Power 105 - 130 VAC, 1.8 A, 50 - 60 Hz
230 VAC, optional
24 VDC, optional
Connection Panel Protected against unauthorized access
Color Gray (painted)
Cooling External Convection
No ventilation slots
3.3 Environmental Specifications
EMI Meets specifications for influx of an
electromagnetic field of 10 V/m between 100 kHz –
1 GHz, excluding band of
operation
Operating
-25 to 50° C. Also conforms to Bellcore
Temperature specification GR-63-CORE, section 5.1.2
Storage
-40 to 75° C
Temperature
Weather Enclosure: NEMA 4 rated
Resistance
Shipping Conforms to Bellcore specification
GR-63-CORE, sections 5.3 and 5.4.3
