locked to this basic oscillator. The same LO frequency is used for both the upconverter
and downconverter, ensuring no difference in the input and output frequencies.
An aluminum case houses the repeater. Cooling fins for the amplifier are located on the
rear of the unit. The choice of aluminum as the case material gives a lightweight design
with good heat conduction and weatherproof protection. The housing conforms to NEMA
4 standard.
The transmit and receive antenna ports are 7/16” standard, with the option of N-type
connectors, located on the underside of the repeater. The external connections on the
bottom of the repeater are protected from unauthorized access with a cover, which can
be opened only from the inside of the repeater.
