Rear Panel & Functions
5. Analog Line Output:
• Le and Right Balanced (XLR) Connectors
• Le and Right Un-Balanced (RCA) Connectors
• Level High/Low switch (Output Line Level with 0dBfs signal on AES/EBU input):
Low position: XLR outputs: 4V (+14.38dBu)
RCA outputs: 2V (+8.353dBu)
High position: XLR outputs: 7.2V (+19.38dBu)
RCA outputs: 3.6V (+13.34dBu)
6. Digital Inputs:
• EMM Optilink: input for interconnection with an EMM Labs transport.
• AES/EBU: AES/EBU (XLR) PCM digital input.
• COAX: SPDIF (RCA) format PCM audio.
• TOS1: SPDIF (TOSLINK) format PCM audio.
• TOS2: SPDIF (TOSLINK) format PCM audio.
• PC AUDIO: USB PCM audio from a computer, media player, server
• PDAI: Connector intended for future use.
7. System
Remote:
• External IR: wired infra-red communication port
• Wired RS232: RS232 communication port
Service:
• USB: soware update port please see Appendix A for details
• RESET: Used to access the backup BIOS in connection with soware
upgrades via the USB port. Should not be used during normal
operation. Please see Appendix A for details.
