Instructions

41
7.1DefinitionofFrontPanel
LEDindicationof°C:
CentigradeUnit
LEDindicationof°F
FahrenheitUnit
LEDindicationofunits
otherthan°Cand°F
LEDindicationof
Output-1,Output-2and
Output-3Status
LEDindicationofSV,Processsetvalue
LEDindicationof AT, Autotuneisactive
Displays
ProcessValue(PV)
andParameter
DisplaysProsesSet
Value
Parameter
(SV)and
Menubutton
Thisbuttonisused
toaccesstotheall
menusandto
moveuptoanother
menuinthemenu
list
Thisbuttonisused
toaccesstothe
processsetvalue
anduseasOK
buttoninprogram
parameters.
Thisbuttonisused
toincreasethe
valueandaccess
tothemenupages
Thisbuttonisused
todecrasethe
valuesandaccess
tothemenupages
7.DefinitionofFrontPaneland AccessingtotheParameters
Note-1: If increment or decrement button is pressed for 5 seconds continuously,
increment and decrement number become 10, if increment or decrement button is
pressed for 10 seconds continuously, increment and decrement number become 100.
Note-1
Note-1
LEDindicationof
Automaticoperation
(Forprocessoutput)
LEDindicationofManual
operation(Forprocess
output)
LEDindicationof
Ramp&Soakoperation
isactive
LEDindicationof
OperationwithRemote
setvalue
Fordetailedinformation;
Pleasereferto
Section8.1.1
(Processand
AlarmSetParameters)
and8.1.3(Function
selectionforTopand
BottomDisplay)
°C
°F
V
Remote
SV
AT
AUTO
MAN
RAMP
O1
O2
O3
ProcessController
ESM-9950
SET
