4.1.5EMI-940Pt-100InputModule
SpecificationsofEMI-940Pt-100InputModule
Accuracy
PleaserefertoSection8.2.3or8.2.4forselectionofinputtypeandscale
Dimensions :
InputResistance :
18x75.2x41.4mm
Greaterthan10MW
: 0.5%
EMI-910, EMI-930, EMI-940 or EMI-950 analog input modules can not be plugged-
in Module-1 and Module-2 socket at the same time.
EMI-910, EMI-930, EMI-940 or EMI-950 analog input modules can not be plugged-
in Module-1 and Module-2 socket at the same time.
4.1.4EMI-930TC(Thermocouple)or0...50mV InputModuleZ
SpecificationsofEMI-930TCor0...50mV InputModule
PleaserefertoSection8.2.3or8.2.4forselectionofinputtypeandscaleofTCinput
type(L,J,K,R,S,T,B,E,N,C)
Z
Accuracy
Dimensions
InputResistance :
:0.3%
:18x75.2x41.4mm
Greaterthan10M W
Applications of EMI-930 0...50mV Input ModuleZ
It can be used to measure any process value and use it with an alarm function in applications that
2nd sensor input is necessary.
The voltage value (0...50mV )on the module input can be used as process set value when
"remote set" function is activated and system can be controlled with analog signal(0..50mV
) which is applied from remote point.
Z
Z
Detailed information about functions of EMI-930 TC or 0...50mV Input Module
are given in parameters section. For using these functions EMI-930 TC or
0...50mV Input Module must be installed to Module-1 or Module-2 socket.
Z
Z
EMI-930 TC or 0...50mV input module
8.2.3 or
8.2.4 for detailed information.( , parameters)
Z can be plugged in Module-1 or Module-2 socket to use
as 2nd sensor input, for measuring process value or for using alarm functions which are related to
measured value.
Also “remote set” function can be used by plugging this module. Please refer to Section
EMI-940 Pt-100 input module can be plugged in Module-1 or Module-2 socket to use as 2nd
sensor input, for measuring process value or for using alarm functions which are related to
measured value.
Also “remote set” function can be used by plugging this module. Please refer to Section 8.2.3 or
8.2.4 for detailed information.( , parameters)
