5.1.6UsingEMI-930TCor0...50mV InputModuleas0...50mV InputZ Z
5.1.7ConnectionofEMI-940PT-100 InputModule
Module-1
Module-2
Module-1
Module-2
There is no line compensation in PT-100 Input Module
EMI-910, EMI-930, EMI-940 or EMI-950 analog input modules can not be plugged-
in Module-1 and Module-2 socket at the same time.
By selecting Module-1 or Module-2 analog input configuration parameter or is
And defining calibration points with dual point calibration property, EMI-930 TC or
0...50mV module can be used as 0...50mV input.Z Z
5.1.8ConnectionofEMI-9500...10VZ InputModule
Module-1
Module-2
EMI-910, EMI-930, EMI-940 or EMI-950 analog input modules can not be plugged-
in Module-1 and Module-2 socket at the same time.
EMI-910, EMI-930, EMI-940 or EMI-950 analog input modules can not be plugged-
in Module-1 and Module-2 socket at the same time.
