Instructions

94
HYS
ProcessSet- AlarmSet
HYS
ON
OFF
Process
Set
ProcessSet+ AlarmSet
Alarm
Output
ProcessValue
HYS
ProcessSet- AlarmSet
HYS
ON
OFF
Process
Set
ProcessSet+ AlarmSet
Alarm
Output
ProcessValue
Deviation Band Alarm
Deviation Range Alarm
Alarm
Status
Alarm
Output
On
Delay
OFF
Delay
Alarm- 1 hysteresis value. It is active if logic output function of Module-
1 is selected alarm output.
If is and there is one of an analog input module ( 2nd
sensor input) in Module-2 socket, then it can be adjusted from 0% to
50% of analog input module scale ( - )
If there is CT input module (EMI-920) in Module-2 socket and alarm
type parameter is , then it can be adjusted from 0.0 to
20.0A
V
V
If is or there is no analog input module ( 2nd sensor input )
in Module-2 socket, then it can be adjusted from 0% to 50% of process
input scale ( - )
Alarm on delay time. It can be adjusted from 0000 to 9999 seconds. It is
active if logic output function of Module-1 is alarm output.
Alarm off delay time. It can be adjusted from 0000 to 9998 seconds.
When the value is greater than 9998, is seen on the display. It
means alarm latching output is selected. It is active if logic output
function of Module-1 is alarm output.
