8.1.1Processand AlarmSETParameters
Parameters are divided into two groups. These can be accessed by operator and
technician. Also, they are grouped into subgroups according to their functions. The subgroups
are named as menu pages.
This is the ’s process set value. Controlling is done according to
this value by process control outputs.
device
If EMO-900 Relay, EMO-910 SSR Driver or EMO-920 Digital
(Transistor) output module is plugged in Module-1 socket and output is
configured as an alarm output, this parameter defines the set value of
the alarm output.
8.Parameters
8.1OperatorParameters
EMO-900
EMO-910
EMO-920
MODULE-2
EMI-910
EMI-930
EMI-940
EMI-950
Process set value can be adjusted from minimum value of set scale
to maximum value of set scale
MODULE-2
EMI-920
Set value of Heating FailureAlarm
Setvaluecanbeadjustedfromminimumvalueofsetscale
tomaximumvalueofsetscale
If CT inputmodule(EMI-920)ispluggedinModule-2socketand
Module-1alarmtypeparameterwhichisexplainedinSection
8.2.3is,parametercanbeadjustedfrom0.0to
100.0A
V
V
If one of the analog input modules is plugged in Module-2 socket and
measurement input selection parameter which is explained in
Section 8.2.3 for Module-1 alarm output is , can be
defined alarm set value for analog input module in Module-2.
Parameter can be adjusted from minimum set value of 2nd
sensor input to maximum set value of 2nd sensor input .
Also point position of parameter and measured value from
analog input module (2nd sensor input) is the same.
In this conditions, alarm output operates according to 2nd sensor input
value and parameter.
