SENSOR BREAK OUTPUT VALUE
(FOR HEATING PID 0.0 , 100.0 )
(FOR COOLING PID -100.0 , 0.0 )
(FOR HEATING-COOLING PID -100.0 , 100.0 )
%%
%%
%%
If > 0 (Dead Band)
If < 0 (Overlap Band)
Process
Output
100%
50%
0%
Process
Value
Heating Set
Value
()
Cooling Set
Value
(+)
Process
Output
100%
50%
0%
Process
Value
Cooling Set
Value
Heating Set
Value
()
When sensor breaks, controlling of the process can continue by
entering %output value to parameter.
If this parameter 0.0 , process control output does not perform an
output when sensor breaks.
(+)
