User manual

5.1.6 Using EMI-430 TC or 0...50mV Input Module as 0...50mV InputZZ
5.1.8 Connection of EMI-450 0...10VZ Input Module
5.1.7 Connection of EMI-440 PT-100 Input Module
34
8
Module-1
7
Transmitter
0-50 mVZ
PV
Module-2Module-1
Pt-100 Pt-100
10
Module-2
9
Transmitter
0-50 mVZ
PV
There is no line compensation in PT-100 Input Module
EMI-410, EMI-430, EMI-440 or EMI-450 analogue input modules can not be
plugged-in Module-1 and Module-2 socket at the same time.
By selecting Module-1 or Module-2 analogue input configuration parameter or
and defining calibration points with dual point calibration property, EMI-430 TC or
0...50mV module can be used as 0...50mV input.ZZ
8
Module-1
7
Transmitter
0...10VZ
PV
10
Module-2
9
Transmitter
PV
EMI-410, EMI-430, EMI-440 or EMI-450 analogue input modules can not be
plugged-in Module-1 and Module-2 socket at the same time.
EMI-410, EMI-430, EMI-440 or EMI-450 analogue input modules can not be
plugged-in Module-1 and Module-2 socket at the same time.
i
i
i
10
9
8
7
0...10VZ
