5.1.5 Connection of EMI-430 TC (Thermocouple) or 0...50mV Input ModuleZ
5.1.4 Current Transformer Connection to EMI-420 0...5 A CT Input ModuleV
0...5AV
0...5AV
Two EMI-420 CT input modules can not be plugged in Module-1 and Module-2
socket at the same time.
V
Current
Transformer
(CT)
Load
33
8
Module-1
7
0.1 W
Current
Transformer
(CT)
Load
10
Module-2
9
Connect the wires with the polarity as shown above. Always use compensation wire
corresponding to the thermocouple used. If present, the shield must be connected to a proper
ground.
10
Module-2
9
8
Module-1
7
TC TC
0.1 W
EMI-410, EMI-430, EMI-440 or EMI-450 analogue input modules can not be
plugged-in Module-1 and Module-2 socket at the same time.
