User manual

5.1.2 Connection of 3-Wire Transmitter to EMI-410 0/4...20 mA Current Input ModuleZ
31
Transmitter
Transmitter
External
Power
Supply
Note 2
PV PV
88
Module-1 Module-1
77
44
Note-1 Note-1
12 V
Maximum
50mA
Z 12 V
Maximum
50mA
Z
Transmitter
Transmitter
External
Power
Supply
Note 2
PV PV
10 10
Module-2 Module-2
99
44
12 V
Maximum
50mA
Z
Note-1 Note-1
12 V
Maximum
50mA
Z
Note 2 : External power supply must be selected according to power supply voltage range and
required current for transmitter.
Note-1 : There is internal 2R7 shuntW
EMI-410, EMI-430, EMI-440 or EMI-450 analogue input modules can not be
plugged-in Module-1 and Module-2 socket at the same time.
Transmitter connection by using supply
voltage on the device
Transmitter connection by using external supply
voltage source.
i
Current
Output
mAZ
Current
Output
mAZ
Current
Output
mA
Z
Current
Output
mA
Z
