LABELS FOR INPUT MODULES
Label which describes terminal connection of module that is
plugged in Module-1 socket is attached to this area.
Label which describes terminal connection of module that is
plugged in Module-2 socket is attached to this area.
Every module which is plugged in Module-1 or Module-2 socket has labels for showing the
relation between connection terminal and the device. These labels are attached to empty boxes
which are d for Module-1 and Module-2 on the device. Labels for all modules and
attachment places are shown below.
separate
4.4 To Stick Input/Output Modules’ Labels to the Device
LABELS FOR OUTPUT MODULES
Label for EMO-400 Relay
Output Module
Label for EMO-410 SSR Driver
Module
Label for EMO-420 Digital
Output Module
Label for EMO-430
0/4...20mA Current Output
Module
Z
28
Label for EMI-400 Digital
Input Module
Label for EMI-440 Pt-100
Input Module
Label for EMI-420 0...5A
CT Input Module
V
Label for
Input Module
EMI-430 TC or
0...50mV Z
Label for EMI-410 0/4...20mA
Current Input ModuleZ
Label for ZEMI-450 0...10V
Input Module
Digital Input
Module
EMI-400
Current Input
Module
EMI-410
0/4 to 20mAZ
CT Input
Module
V
EMI-420
0to5AV
TC or
EMI-430
0 to 50mVZ
Input Module
Pt-100 Input
Module
EMI-440
Pt-100
0to10V
Input Module
Z
EMI-450
NOC
Relay Output
Module
EMO-400
3A@250V V
SSR Driver
ModuleOutput
EMO-410
Max.
20mA@18VZ
Digital
Module
Output
EMO-420
Max.
40mA@18VZ
0/4 to 20mAZ
Current
Module
Output
EMO-430
+ -
+ -
