4.2.4 EMO-4300/4...20mA Current Output ModuleZ

4.2.3 EMO-420 Digital (Transistor) Output Module

Specifications of EMO-420 Digital (Transistor) Output Module

Output :

Dimensions :

Maximum 40 mA, 15-18V

14x30.7x41.4mm

Z ±10%, isolated

EMO-420 Digital (Transistor) Output Module can be plugged in Module-1 or Module-2 socket to

use functions which are defined for digital output.

Applications of EMO-420 Digital (Transistor) Output Module

It can be used with heating or cooling functions as process control output, as alarm output by

programmable different alarm functions, as logic output to transfer some datas on the device to

the system. These alternatives are explained in parameters section as logic output function.

Detailed information about functions of EMO-420 Digital (Transistor) Output

Module are given in parameters section. For using these functions EMO-420

Digital (Transistor) Output Module must be installed to Module-1 or Module-2

socket.

Specifications of EMO-430 0/4...20mA Current Output ModuleZ

Output :

Accuracy :

Note : ,

Maximum load impedance :

Dimensions :

0/4...20mA current output

To get 0...10V 500 resistor with 0.05% tolerance must be connected in parallel

as a shunt resistor to module output (Please refer to Section 5.2.5 for detailed information)

600

14x30.7x41.4mm

Z W

EMO-430 0/4...20mA Current Output Module can be plugged in Module-1 or Module-2 socket

to use functions which are defined for current output.

Applications of EMO-430 0/4...20mA Current Output ModuleZ

It can be used in heating or cooling functions as process control output.

Process value, difference between process and set value or set value can be retransmitted to the

system as 0...20mA or 4...20mA output. Retransmission is explained in parameters

section.

Detailed information about functions of EMO-430 Current Output Module are

given in parameters section. For using these functions EMO-430 0/4...20mA

current Output Module must be installed to Module-1 or Module-2 socket.
