User manual

EMI-450 0...10V input module can be plugged in Module-1 or Module-2 socket to use as 2nd
sensor input, for measuring process value or for using alarm functions which are related to
measured value.(In some sections it is defined as analogue input module)
Also “remote set” function can be used by plugging this module. Please refer to Section 8.2.3 or
8.2.4 for detailed information.( , parameters)
Z
4.1.6 EMI-450 0...10V Input ModuleZ
24
EMI-410, EMI-430, EMI-440 or EMI-450 analogue input modules can not be
plugged-in Module-1 and Module-2 socket at the same time.
Specifications of EMI-450 0...10V Input ModuleZ
Accuracy :
Dimensions :
Input Resistance :
0.3%
14x30.7x41.4mm
43K .W
Applications of EMI-450 0...10V Input ModuleZ
It can be used to measure any process value and use it with an alarm function in applications that
2nd sensor input is necessary.
(0...10V ) value on module input can be used as process set value when “remote set” function
is activated and system can be controlled with analogue signal(0...10V ) which is applied from
remote point.
Z
Z
Detailed information about functions of EMI-450 0...10mV Input Module are
given in parameters section. For using these functions EMI-450 0...10mV
Input Module must be installed to Module-1 or Module-2 socket.
Z
Z
i
i
For using EMI-450 0...10V input module as 0...10V , or
Must be
ZZ
Applications of EMI-440 Pt-100 Input Module
It can be used to measure any process value and use it with an alarm function in applications that
2nd sensor input is necessary.
The Pt-100 value on the module input can be used as process set value when “remote set”
function is activated and system can be controlled with analogue signal which is applied from
remote point.
Detailed information about functions of EMI-440 Pt-100 input module are given
in PARAMETERS section. For using these functions EMI-440 Pt-100 input
module must be installed to Module-1 or Module-2 socket.
i
i
