User manual

4.1.5 EMI-440 Pt-100 Input Module

4.1.4 EMI-430 TC (Thermocouple) or 0...50mV Input ModuleZ

Specifications of EMI-440 Pt-100 Input Module

Accuracy

Please refer to Section 8.2.3 or 8.2.4 for selection of input type and scale

Dimensions :

Input Resistance :

14x30.7x41.4mm

Greater than 10MW

: 0.5%

EMI-410, EMI-430, EMI-440 or EMI-450 analogue input modules can not be

plugged-in Module-1 and Module-2 socket at the same time.

EMI-410, EMI-430, EMI-440 or EMI-450 analogue input modules can not be

plugged-in Module-1 and Module-2 socket at the same time.

Specifications of EMI-430 TC or 0...50mV Input Module

Please refer to Section 8.2.3 or 8.2.4 for selection of input type and scale of TC input

type (L, J, K, R, S, T, B, E, N,C)

Accuracy :

Dimensions :

Input Resistance :

0.3%

14x30.7x41.4mm

Greater than 10M W

Applications of EMI-430 0...50mV Input ModuleZ

It can be used to measure any process value and use it with an alarm function in applications that

2nd sensor input is necessary.

The voltage value (0...50mV ) on the module input can be used as process set value when

"remote set" function is activated and system can be controlled with analogue signal(0..50mV

) which is applied from remote point.

Detailed information about functions of EMI-430 TC or 0...50mV Input

Module are given in parameters section. For using these functions EMI-430 TC or

0...50mV Input Module must be installed to Module-1 or Module-2 socket.

EMI-430 TC or 0...50mV input module

8.2.3 or

8.2.4 for detailed information.( , parameters)

Z can be plugged in Module-1 or Module-2 socket to use

as 2nd sensor input, for measuring process value or for using alarm functions which are related to

measured value.

Also “remote set” function can be used by plugging this module. Please refer to Section

EMI-440 Pt-100 input module can be plugged in Module-1 or Module-2 socket to use as 2nd

sensor input, for measuring process value or for using alarm functions which are related to

measured value.

Also “remote set” function can be used by plugging this module. Please refer to Section 8.2.3 or

8.2.4 for detailed information.( , parameters)

For using EMI-430 TC or 0...50mV input module as 0...50mV , or

must be
