4.1.3 EMI-420 0...5A CT Input ModuleV
4.1.2 EMI-410 0/4...20mA Current Input ModuleZ
22
Specifications of EMI-410 0/4...20mA Current Input ModuleZ
Input Type : 0/4...20 mA Current Input
Accuracy : 0.3%
Dimensions : 14x30.7x41.4mm
Input Resistance : 2R7
Z
W .
Applications of EMI-410 0/4...20mA Current Input ModuleZ
It can be used to measure any process value and use it with an alarm function in applications that
2nd sensor input is necessary.
The current value (0/4...20mA ) on the module input can be used as process set value when
“remote set” function is activated and system can be controlled with analogue signal (0/4...20 mA
) which is applied from remote point.
Z
Z
Detailed information about functions of EMI-410 0/4...20mA Current Input
Module functions are given in parameters section. For using these functions
EMI-410 0/4...20mA Current Input Module must be installed to Module-1 or
Module-2 socket.
Z
Z
Specifications of EMI-420 0...5A CT Input ModuleV
Input Type : 0...5A
Accuracy : 2% FS
Dimensions :14x30.7x41.4mm
Input Resistance :23m
V
W .
Applications of EMI- Input Module420 0...5A CTV
It can be used for observing heater current with current transformer and detecting heating failure.
Detailed information about functions of EMI-420 0...5A CT Input Module
functions are given in parameters section. For using these functions, EMI-
420 0...5A CT Input Module must be installed to Module-1 or Module-2
socket.
V
V
EMI-420 0...5A CT Input Module can be plugged in Module-1 or Module-2 socket for detecting
heater failures in any applications.
V
EMI-410, EMI-430, EMI-440 or EMI-450 analogue input modules can not be
plugged-in Module-1 and Module-2 socket at the same time.
Two EMI-420 CT input modules can not be plugged in Module-1 and Module-
2 socket at the same time.
V
EMI-410 0/4...20mA current input module can be plugged in Module-1 or Module-2 socket to
use as 2nd sensor input, for measuring process value or for using alarm functions which are
related to measured value.
8.2.3 or
8.2.4 for detailed information ( , parameters)
Z
Also,”remote set” function can be used by installing the module. Please refer to Section
