User manual

3.5 Relay Output Connection
19
Fuses must be selected according to the application.
c
Device
Fuse
Load
LN
Last Control Element
(Contactor)
c
3.4.5 Connection of Transmitters with Voltage Output to Process Input
Transmitter
Transmitter
External
Power
Supply
Note 1
mV, VZ mV, VZ
PV PV
11
22
44
12 V
Max. 50mA
Z12 V
Max. 50mA
Z
5A T FuseV
Transmitter connection by using supply
voltage on the device
Transmitter connection by using external supply
voltage source.
Note 1 : External power supply must be selected according to supply voltage range and
required current for transmitter.
Input resistance is greater than 10M 0...50mV
Input resistance is 43K for0...10V
W
W
for Z
Z
i
5
6
C
NO
