User manual

10. Specifications
Device Type
Housing&Mounting
Protection Class
Weight
Environmental Ratings
Storage/Operating Temperature
Storage/Operating Humidity
Installation
Overvoltage Category
Pollution Degree
Operating Conditions
Supply Voltage and Power
Process Inputs
Thermocouple Input Types
Thermoresistance Input Types
Voltage Input Types
Current Input Types
Accuracy
Cold Junction Compensation
Line Compensation
Sensor Break Protection
Sampling Cycle
Input Filter
Control Forms
Standard Relay Output
Optional Output Modules
Optional Input Modules
Standard Communication Module
Optional Communication Module
Communication Protocol
Process Display
Set Display
Led Indicators
: Process Controller
: 48mm x 48mm x 116mm 1/16 DIN 43700 plastic housing for panel
mounting. Panel cut-out is 46x46mm.
: NEMA 4X (IP65 at front, IP20 at rear).
: Approximately 0.21 Kg.
: Standard, indoor at an altitude of less than 2000 meters
with none condensing humidity.
: -40 C to +85 C / 0 C to +50 C
: 90 % max. (None condensing)
: Fixed installation
:II
: II, office or workplace, none conductive pollution
: Continuous
: 100 - 240 V (-15% / +10%) 50/60 Hz 6VA
24 V (-15% / +10%) 50/60 Hz 6VA
24 V (-15% / +10%) 6W
: Universal input TC, RTD, Voltage/Current
: Selectable by parameters
L (DIN43710) ,
J ,K ,R ,S ,T ,B ,E ,N (IEC584.1)(ITS90) , C (ITS90)
: PT 100 (IEC751) (ITS90)
: Selectable by parameters 0...50mV , 0...5V ,
0...10V
: Selectable by parameters 0...20mA , 4...20mA
: ± 0,25% of full scale for thermocouple, thermoresistance
and voltage,
± 0,70% of full scale for current.
: Automatically ± 0.1°C/1°C.
: Maximum 10 .
: Upscale
: 3 samples per second
: 0.0 to 900.0 seconds
: Programmable ON / OFF, P, PI, PD or PID.
:5
(Electrical Life : 100.000 Operation (Full Load))
:-EMO-400 Relay Output Module (3A@250V at resistive load)
(Electrical Life : 100.000 Operation (Full Load))
-EMO-410 SSR Driver Output Module (Max20mA@18V )
-EMO-420 Digital (Transistor) Output Module
(Max 40mA@18V )
-
:-EMI-400 Digital Input Module
-
-EMI-420 0...5A CT Input Module
-EMI-430 TC or 0...50mV Input Module
-EMI-440 PT-100 Input Module
-EMI-450 0...10V Input Module
: EMC-400 RS-232 Communication Module
: EMC-410 RS-485 Communication Module
: MODBUS-RTU
:10.1 mm Red 4 digits LED display
: 8 mm Green 4 digits LED display
: AT (Auto Tune), SV (Set value), Man (Manual Mode),
Auto (Automatic Mode), O1/2/3(Outputs) Leds,
°C / °F / V unit, Ramp, Remote Leds
oooo
V
V
Z
Z
Z ZZ
Z
Z ZZ
V
Z
Z
V
Z
W
A @ 250V at resistive loadV
EMO-430 0/4...20mA Current Output Module
EMI-410 0/4...20mA Current Input Module
: UL Recognized Component (File No : E 254103), GOST-R,
Z
Z
Approvals
