9. Failure Messages in ESM-4450 Process Controllers
3 - If parameter is and parameter is and
analogue input module is plugged in Module-1 or Module-2 socket, this
is sensor failure of analogue input module. Sensor connection is wrong
or there is no sensor connection.
122
1 - Sensor failure in analogue inputs. Sensor connection is wrong or
there is no sensor connection.
Please refer to Section 8.1.3 for detailed information about this
parameter.
2 - If parameter in “Disp List” menu is and analogue input
module is plugged in Module-1 or Module-2 socket, this is sensor
failure of analogue input module. Sensor connection is wrong or there
is no sensor connection.
In “PınP Conf” Menu if;
=; =; = ;
= ; = are defined.
Adjust Þ
If analogue input value is less than minimum value of operating scale
top display starts to blink.
4 - If top display blinks : If analogue input value is less than minimum
value of operating scale top display starts to blink.
Please refer to Section 8.1.3 for detailed information about this
parameter.
Please refer to Section 8.2.1 for detailed information about this
parameter.
