User manual

Motor travel time. It can be adjusted from seconds.5 to 600
(It is active if motorized valve control is selected)
119
Minimum value for process set and alarm set values. It is named as low
limit of set scale.
8.2.1 Process Input Type and Relevant
Parameters with Process Input for parameter
It can be adjusted from low limit of input selected with parameter
to parameter.
Please refer to Section
Maximum value for process set and alarm set values. It is named as
high limit of set scale.
8.2.1 Process Input Type and Relevant
Parameters with Process Input for parameter
It can be adjusted from to high limit of input selected with
Parameter.
Please refer to Section
Minimum value for set value of second sensor (analogue input module)
in Module-1 or Module-2 socket. It is named as low limit of set scale for
second sensor.
It can be adjusted from low limit of analogue input selected with
or Parameter to parameter.
Please refer to Section 8.2.3 (Module-1 Configuration Parameters)
and Section 8.2.4 (Module-2 Configuration Parameter) for and
Parameters.
(This parameter is visible if one of the analogue input modules is
plugged in Module-1 or Module-2 socket)
Minimum time of motorized valve output activation. It can be adjusted
from to
If = 100 sec and = 1.0 m
is 100 * 1.0 = 1 sec
0.1 5.0%%.
(It is active if motorized valve control is selected)
% then inimum time of motorized
valve output activation %
Maximum value for set value of second sensor (analogue input
module) in Module-1 or Module-2 socket. It is named as high limit offset
scale for second sensor.
It can be adjusted from to high limit of analogue input selected
with Parameter to parameter.
Please refer to Section 8.2.3 (Module-1 Configuration Parameters)
and Section 8.2.4 (Module-2 Configuration Parameter) for and
Parameters.
(This parameter is visible if one of the analogue input modules is
plugged in Module-1 or Module-2 socket)
8.2.6 General Parameters
