These parameters are active if EMI-400 (Digital Input) is plugged in
Module-2 socket.
EMI-400
Ramp&Soak, Start / Stop input
Manual /Automatic selection input
Auto Tune ( Limit Cycle Tuning) Start/Stop input
Ramp&Soak, Start / Hold input
When the logic input is triggered ;
When the logic input is triggered ;
When the logic input is triggered ;
When the logic input is triggered ;
Alarm Latch Canceling.
When the logic input is triggered ;
Configuration of digital input in Module-2 socket.
In PID Tune and selection of operation form menu (
(Auto) is ,
then is selected, ifAuto parameter is , then
is selected.
run List) ,
if selection of operation form parameter
If Ramp / Soak control parameter is
or then is selected
If it is then is selected.
If Ramp / Soak control parameter is
then is selected
then is selected
If there is a latching alarm output and alarm condition is not
active, latching is canceled.
It is used to start or stop the Auto Tune operation.
If input is being active while operation does not
perform, automatic tune selection parameter is
selected and then Auto Tune operation starts to run.
If input is being active while Atun operation performs, Auto
Tune operation is stopped.
