These parameters are active if EMO-430 (
) module is plugged in Module-2 socket.
0/4...20mA Current
Output
Z
Analogue output module in Module-2 socket is used for
cooling
0...20mA output or 0...10V according to Section 5.2.5 is
selected.
Z
4...20mA output or 2...10V according to Section 5.2.5 is
selected.
Z
Analogue output module in Module-2 socket is used for re-
transmission”
EMO-430
Configuration of analogue output module in Module-2 socket.
Function selection of analogue output module in Module-2 socket.
Analogue output module in Module-2 socket is used for
heating
Defines (It is active if Re-transmission” . re-transmission”function
function is selected for analogue output module in Module-2 socket)
It retransmits Process value to analogue output.
It retransmits difference between Process and Set value to
analogue output.
It retransmits Set value to analogue output.
i
Scale
020
mA
UPL
LOL
Re-transmission
