Instructions

Gen ConF: General Parameters
Alarm Set Values Protection
Alarm Set values can be changed.
Alarm Set values can not be changed. Alarm set values
Parameters ( and ) are not accessible.
AUTO / MANUAL Selection Button Protection
Auto or Manual selection is possible with A/M button in
Main Operation screen.
Auto or Manual selection is not possible with A/M button in
Main Operation screen.
Process Set Value Low Limit ( , )Unit
AT (AUTO TUNE) Button Protection
Limit Cycle Tuning operation can be active or inactive with
AT(Auto Tune) Button in Main Operation screen.
Limit Cycle Tuning operation can not be active or inactive with
AT(Auto Tune) Button in Main Operation screen.
Process Set Value Up Limit ( , )Unit
It is used for accessing to the technician parameters.
It can be adjusted from 0 to 9999.
If it is ; there is no password protection while entering to
the technician parameters.
If this parameter is different from “ 0” and user wants to
access to the technician parameters;
1- If technician does not enter password correctly:
It turns to operation screen without entering to technician
parameters.
2- When in top display and in bottom display, if
technician presses SET button without entering password (For
observing parameter)
Technician can see all menus and parameters except Technician
Password menu (“Pass Conf”), but parameters can not be
changed.
Technician Password (0, 9999)
PASS ConF: Technician Password
15
