Instruction manual

Page 12 Emhart Teknologies - 50 Shelton Technology Center, Shelton CT 06484 - Tel. [phone] - Fax [phone]
ProSet
®
2500 Parts List
Item Part No. Description 2500
2500
MCS
1 PRN614 Nose Piece 1 1
2 13300 13300
1set(3) 1set(3)
3 DPN275-001 Jaw Guide 1 1
4 DPN275-002 Pulling Head 1 1
5 DPN275-003 Jaw Guide Lock 1 1
6 DPN275-004 Nose Housing 1 1
7 DPN900-027 O-Ring 1 1
8 DPN275-005 Nose Housing Nut 1 1
9 DPN275-027 Jaw Pusher 1 1
10 DPN901-005 Jaw Pusher Spring 1 1
11 DPN901-006 Spring 1 1
12 DPN275-006 Spring Receiver 1 1
13 DPN275-007 Hydraulic Piston 1 1
14 DPN275-008 Housing Adapter 1 1
15 DPN900-024 O-Ring 1 1
16 DPN275-009 Rod Seal Case 1 1
17 DPN908-007 Scraper 1 1
18 DPN900-029 O-Ring 2 2
19 DPN908-006 B.U-Ring 2 2
20 DPN908-005 Penta Seal 2 2
21 DPN908-008 B.U-Ring 1 1
22 DPN900-028 O-Ring 1 1
23 DPN275-010 Handle Upper 1 1
24 DPN901-007 Return Spring 1 1
25 DPN900-005 O-Ring 2 2
26 DPN239-111 MCS Valve Rod 1 1
27 DPN275-031 MCS Cap 1 1
28 DPN275-032 End Cap Adapter 1 1
29 DPN900-019 O-Ring 2 2
30 DPN275-033 Slider 1 1
31 DPN275-037 Slider Pusher 1 1
32 DPN900-026 O-Ring 1 1
33 DPN239-153 End Cap 1 1
34 DPN239-116 Collar 2 2
35 DPN239-154 Collar Screw 2 2
36 DPN275-034 Ejector Guide 1 1
37 DPN900-006 O-Ring 2 2
38 DPN907-002
Socket Head Cap Screw
4 4
39 DPN239-119 End Cap Plate - 1
40 FAN275-011 Ejector (Assembly) 1 1
44 DPN239-108 Packing 1 1
45 DPN239-047 Fill Screw 1 1
46 DPN900-007 O-Ring 2 2
47 DPN900-008 O-Ring 1 1
48 DPN900-009 O-Ring 1 1
49 DPN275-014 Sleeve Upper 1 1
50 DPN239-052 Upper Plate 1 1
51 DPN239-053 Sleeve Lower 1 1
54 FAN275-015
Handle Lower Assembly
1 1
57 FAN275-018 Air Piston Assembly 1 1
60 DPN900-025 O-Ring 1 1
61 DPN239-063 Sleeve Lock Nut 1 1
62 DPN239-064 Bottom Plate 1 1
63 DPN239-065 J Valve Cap 1 1
64 DPN900-011 O-Ring 2 2
65 DPN900-012 O-Ring 1 1
66 DPN239-068 J Valve Rod 1 1
67 DPN239-069 EXT Silencer 1 1
68 DPN900-013 O-Ring 3 3
69 DPN239-071 Valve Stopper 1 1
70 DPN239-120 Fitting 4 4
71 DPN239-121 Air Tube 2 2
72 FAN239-074 S.V Case Assembly 1 1
75 DPN900-014 O-Ring 2 2
Item Part No. Description 2500
2500
MCS
76 DPN902-001 Retaining Ring 1 1
77 DPN239-078 S Valve Rod 1 1
78 DPN906-001
Button Head Cap Screw
1 1
79 DPN239-150 Trigger 1 1
80 DPN239-083 Connect Tube 1 1
81 DPN900-015 O-Ring 2 2
82 DPN239-151 Handle Assembly 1 1
83 DPN907-001
Socket Head Cap Screw
3 3
84 DPN239-086 Hexagon Nut 4 4
85 DPN907-004
Socket Head Cap Screw
1 1
86 DPN900-016 O-Ring 1 1
87 DPN239-089 Plug 1 1
88 DPN907-003
Socket Head Cap Screw
4 4
89 DPN275-021 Chamber 1 1
90 DPN239-126 R Joint Spacer 1 1
91 DPN239-093 R Joint 1 1
92 DPN239-127 R Joint Adapter 1 1
93 DPN239-095 O S Slider 1 1
94 DPN900-017 O-Ring 2 2
95 DPN239-097 O S Joint 1 1
96 FAN275-035 Collector (Assembly) - 1
97 DPN239-098 Collector Lock Collar - 1
98 DPN900-018 O-Ring - 1
99 DPN903-001
Flat Head Cap Screw
- 3
100 DPN239-155 Collector Lock - 1
101 DPN275-036 Collector Body - 1
102 DPN900-020 O-Ring - 1
103 DPN239-168 Collector Silencer - 1
104 DPN239-156 Collector End - 1
105 DPN239-167 Collector End Cap - 1
106 DPN239-152 Collector End Nut - 1
107 DPN900-021 O-Ring 1 -
108 DPN239-163 Deflector Adapter 1 -
109 DPN900-022 O-Ring 1 -
110 PRG510-56 Deflector 1 -
111 FAN275-028
Jaw Pusher Assembly
1 1
114 FAN239-157 Air Line Assembly 1 1
115 DPN239-158 Air Line 1 1
116 DPN239-159 Air Line Fitting 1 1
117 DPN239-160 Hose Female Fitting 1 1
118 PRG540-45 O-Clamp (0911) 2 2
119 PRN414 Nose Piece 4Size 1 1
120 PRN514 Nose Piece 5Size 1 1
121 FAN275-022 EXT Valve Assembly 1 1
122 DPN275-025 EXT Valve Head 1 1
123 DPN275-024 EXT Valve Case 1 1
124 DPN901-008 EXT Valve Spring 1 1
125 DPN900-030 O-Ring 1 1
126 DPN275-023 EXT Valve Rod 1 1
128 DPN275-026 Washer 1 1
NS DPN239-139 HS Screw key - M4 1 1
