2.2 Parts and function
USB Fieldbus InterfaceFigure 2-2:
1 Field connection indicator light
(*)
Indicates the fieldbus device connection status
2 Power indicator light
(*)
Indicates the power mode of the interface
3 USB port Enables USB connection
4 Fieldbus device connection socket Enables fieldbus device or segment connection
(*) See the Indicator light scenarios table.
