Table Of Contents
- Contents
- Housings
- Applications
- Interface/display
- Electrical connections
- Input signals
- Output signals
- Output signals continued
- Environmental specifications
- Power supply
- Hazardous area classifications
- Model 3100 accessory
- Model 3500/3700 liquid flow performance
- Model 3500/3700 density performance (liquid only)
- Model 3500/3700 gas flow performance
- Weight
- Dimensions
- Ordering information
14 Micro Motion
®
Series 3000 Transmitters and Discrete Controllers
Dimensions continued
Panel-mount Model 3300/3500 with optional I/O cable
Bezel
6
(152)
Frame
8 3/4
(222)
5 5/16
(135)
6 11/16
(170)
Minimum 4 1/4″
(108 mm) bend radius
Approvals tag
6 1/2
(165)
1/2
(12)
Dimensions in
inches
(mm)
Panel
6
(152)
DIN-rail-mount
screw terminals detail
3 3/64
(77)
2 37/64
(66)
2 31/64
(63)
2 19/64
(59)
2 1/4
(57)
9
(229)
2 15/64
(57)
3 17/32
(90)
DIN rail type TS 32
DIN rail type TS 35 × 15
DIN rail type TS 15
DIN rail type TS 35 × 7.5
